Multimode OM4 Duplex 3m 5m 7m PVC Lc Lc Fiber Patch Cord

Name: Multimode OM4 Duplex 3m 5m 7m PVC Lc Lc Fiber Patch Cord
Brand: UNIFIBER-OEM
Price: 1 USD

Buy cheap Multimode OM4 Duplex 3m 5m 7m PVC Lc Lc Fiber Patch Cord product

Brand Name : UNIFIBER-OEM

Model Number : LC-LC

Certification : ROHS

Place of Origin : CHINA

MOQ : 10pcs

Price : Negotiable

Payment Terms : Western Union, T/T

Supply Ability : 10000PCS/DAY

Delivery Time : 3-5days

Packaging Details : PE bag

Connector : LC FC SC ST

Fiber Count : Duplex

Cable Jacket : PVC/LSZH/OFNR

Fiber type : 50/125um OM4

Color : Aqua or Violet

Application : Telecom/Data center

Contact Now

LC-LC OM4 Multimode Fiber Jumper Cable Duplex 3m 5m 7m PVC (OFNR) 2.0mm for 40G/100G high density cabling

This 50/125 OM4 multimode fiber optic cable is ideal for connecting 40G BIDI SR, 10G SR, QSFP+, SFP+ transceivers etc. for 10G/40G/100G Ethernet connections and is the preferred fiber specification for 40G/100G applications.The 50/125μm OM4 multimode bend insensitive fiber optic cable is less attenuation when bent or twisted compared with traditional optical fiber cables and this will make the installation and maintenance of the fiber optic cables more efficient. It can also save more space for your high density cabling in data centers, enterprise networks, telecom room, server farms, cloud storage networks, and any places fiber patch cables are needed.

FEATURES

High-quality connectors and Zirconia Ceramic Ferrule
Low insertion Loss and High Return Loss

Enhanced optical performance to meet telecom requirement
IEC, EIA/TIA and Telcordia compliant
RoHS, REACH and SvHC compliant

APPLICATION
Telecom room
Server farms
Cloud storage networks

Data centers

Enterprise networks

Parameters

Connector	LC to LC	Jacket OD	2.0/3.0mm
Fiber Mode	9/125μm or 50/125um	Jacket Color	Yellow/Aqua or Violet
Polish	PC to PC	Wavelength	1310/1550nm
Cable Type	Duplex	Jacket Material	LSZH, OFNP
Insertion loss	≤0.3dB(max)	Interchangeability	≤0.2dB
Return loss	≥50dB(min)	Vibration	≤0.2dB
Operating temperature	-40~75°C	Storage temperature	-45~85°C
Polarity	A(Tx) to B(Rx)	Fiber Grade	9/125 50/125 OM3 OM4

Multimode OM4 Duplex 3m 5m 7m PVC Lc Lc Fiber Patch Cord

Product Tags:

1550nm multimode fiber optic cable

Duplex fiber optic patch leads

Multimode OM4 Duplex 3m 5m 7m PVC Lc Lc Fiber Patch Cord Images
